3.1.3: Modify Model

Previous3.1.2 Disassemble ModelNext3.1.4: Connected Parts

Last updated 7 months ago

If you need to change the nodal positions of an existing model, the “ModifyModel” component is useful. The “Pt” input expects the list of new points to be used as the model's new nodal positions (see Fig. 3.1.3.1). This can be used, for example, to impose imperfections based on the structure's first buckling mode.

24KB
ModifyModel_simple.gh
Fig. 3.1.3.1: The “ModifyModel”-component changes the nodal positions of model.
